- Low insertion loss
- Corrosion resistant body
- Ultra low back reflection
- For 3.0mm, 2.0mm jacket or 900um buffer
- One Piece with pre-domed ceramic ferrule is designed for easy assembly
- Meets Telecordia-GR-326-CORE specifications
| Item | Parameter | |
| Connector Type |
ST、SC、FC、LC、MTRJ、MU、E2000 |
|
| Fiber Type | SM | MM |
| Color | Blue, Green, Metallic | Beige, Metallic, Aqua |
| Testing Wavelength | 1310nm, 1550nm | 850nm, 1300nm |
| Insertion Loss | Typical≤0.20dB,max.≤0.30dB | |
| Repeatability | ≤0.20dB | |
| Exchangeability | ≤0.20dB | |
| Durability | 1000 Mating, max≤0.20dB | |
| Channel Number | Single core, dual-core | |
| Housing Material | Plastic or metal | |
| Boot(Option) | 3.0mm, 2.0mm or 0.9mm | |
| Ferrule | Ceramic (ZrO2) or customized | |
| Operating Temperature | -40℃ to +80℃ | |
| Storage Temperature | -40℃ to +85℃ | |
