SN Patch Cord

SKU af73299ca1f2 Category

SN and CS are both compact dual core connectors. Compared
with high-density LC connector, the density of SN is increased by
40%. CS supports four fiber application of OSFP, the installation
density of LC is doubled the pitch of SN is only 3.1 mm, which
is more compact and supports 8-fiber application

Buy Now
  • Compared with duplex connector, the size is greatly reduced
  • Designed for QSFP-DD applications
  • Suitable for 1.25mm plug
  • The QSFP-DD module can accommodate for SN connectors



Mechanical Data Value
Connector Type SN
Polarity Type A to B, A to A
Cable Diameter 1.6 mm
Cable Jecket Color Yellow, Orange, Aqua, Violet and OEM colors



Optical Data Value
Fiber Mode OS1/OS2/G657‒9/125 bend insensitive(A.1 or A.2) or OM1/2/3/4/5
Fully Compliant 1310nm/1550nm (Singlemode), 850nm/1300nm (Multimode
Insertion loss (Low Loss Singlemode≤0.15dB, Multimode≤0.15dB
Insertion loss (Standard Loss) Singlemode≤0.30dB, Multimode≤0.30dB
Return Loss Singlemode UPC≥55dB APC≥65dB
Multimode UPC≥25dB

SN Patch Cord

SN Patch Cord
